商品の詳細:
|
| 原材料: | 1.5 | 2.5mm （厚い版の薄い版そして低い強さの高力） | 使用法: | トラックのパネル |
|---|---|---|---|
| 作業原則: | 転がり機械を形作る | シーム: | 溶接 |
| スチールプレート材料: | Q235または他 | デコイラー: | 自動decoiler |
| せん断: | 油圧またはディスクせん断 | 制御方法: | PLC制御システム |
| ハイライト: | fully automatic truck body panel roll forming machine,external truck panel roll forming machine,batch production roll forming machine for side panels |
||
| NO. | Item Name | Model/Configuration | Qty | Power (KW) | Key Notes |
|---|---|---|---|---|---|
| 1 | Automatic Decoiler | 10T Capacity | 1 SET | - | Handles maximum 10t steel coils |
| 2 | Metal Embossing Machine | With Separated PLC | 1 SET | 7.5 | Independent PLC control |
| 3 | Servo Coil Feeder | - | 1 SET | 11 | Servo-driven for accurate feeding |
| 4 | Hydraulic Punching & Notch Machine | - | 1 SET | - | Uses SKD11 tooling for durability |
| 5 | Main Rolling Machine | Molding Frame + Gearbox System | 1 SET | 37 | Core forming component |
| 6 | Spot Welding Machine | Tracking Roller Structure | 1 SET | 200 | 2 sets of spot welders |
| 7 | Turkey System | - | 1 SET | - | Enhances panel flatness |
| 8 | Hydraulic Tracking Shearing System | - | 1 SET | 7.5 | Servo-tracking for precise cutting |
| 9 | Receiving Table | - | 1 SET | - | Collects finished panels |
| 10 | PLC Control System | Whole Line Control | 1 SET | - | Centralizes control for all processes |
